| GPC-3060D 线性直流电源 | | | 品牌：台湾固纬 型号：GPC-3060D | |
详细技术指标
| OPERATION MODE | | Independent | (0~30V/0~6A) x 2, (5V/3A Max.) x 1 | | Series | 60V 6A | | Parallel | 30V 12A | | 5V FIXED OUTPUT | | Line Regulation | < 5mV | | Load Regulation | < 10mV | | Ripple & Noise | < 2mVrms | | Voltage Accuracy | 5V±0.25V | | Output Current | 3A | | TRACKING OPERATION | | Tracking Error | < 0.5% + 10mV of the master | | Series Regulation | < 300mV | | ConSTANT VOLTAGE OPERATION | | Line Regulation | < 0.01%+3mV | | Load Regulation | <0.01% + 3mV (rating current <3A)
< 0.02% + 5mV (rating current <10A) | | Ripple & Noise | < 1mVrms 5Hz ~ 1MHz | | Current Output | < 100μS ( 50% load change, minimum load 0.5A ) | | ConSTANT CURRENT OPERATION | | Line Regulation | < 0.2% + 3mA | | Load Regulation | < 0.2% + 3mA | | Ripple & Noise | < 3mArms | | METER | | Type | 3 1/2 digit 0.5" LED display | | Accuracy | ±( 0.5% of rdg + 2 digits ) | | INSULATION | | Chassis and Terminal | 20MΩ or above (DC 500V) | | Chassis and AC Cord | 30MΩ or above (DC 500V) | | POWER SOURCE | | | | AC 100V/120V/220V/240V ±10%, 50/60Hz | | ACCESSORIES | | | User manual x 1
Power cord x 1
Test lead GTL-104 x 2 (<10A), GTL-105 x 1(<3A)
European test lead GTL-204 x 2(<10A), GTL-203 x 1(<3A) | | DIMENSIONS & WEIGHT | | | | 255(W) x 145(H) x 346(D)mm
Approx. 18.5kg | 特点
．三组输出 (两组可调，一组固定电压)
． 自动 Tracking
． 自动串并联操作
． 固定电压与固定电流操作功能
． 低涟波与低杂讯
． 具可选择连续或动态负载
． 过载与极性反向保护功能
．3 1/2 位数 0.5" LED 显示
． 5V, 3A 固定输出
|
